VIVOTEK's FD9181-HT is a brand-new professional H.265 high-efficiency indoor dome network camera, offering 30 fps @ 5-Megapixel or 60 fps @ 1080p with outstanding image quality. By employing H.265 technology, the camera is able to provide higher and more efficient image compression rates than previous H.264 systems. In addition, VIVOTEK's sophisticated Smart Stream II technology enables the cameras to optimize quality for desired regions and therefore to maximize efficiency of bandwidth usage. Combining both H.265 and Smart Stream II, the FD9181-HT can reduce bandwidth and storage consumption by up to 80%* while retaining exceptional 5-Megapixel image quality.
Overview
Specifications
Model
FD9181-HT
System Information
CPU
Multimedia SoC (System-on-Chip)
Flash
128 MB
RAM
512 MB
Camera Features
Image Sensor
1/1.8" Progressive CMOS
Maximum Resolution
2560x1920 (5MP)
Lens Type
Vari-Focal
Focal Length
f = 4 ~ 9 mm
Aperture
F1.3 ~ F2.2
Auto-iris
P-iris
Field of View
45° ~ 93° (Horizontal)
34° ~ 68° (Vertical)
64° ~ 121 (Diagonal)
Shutter Time
1/5 sec. to 1/32,000 sec.
WDR Technology
WDR Pro
Day/Night
Removable IR-cut filter for day & night function
Minimum Illumination
0.04 Lux @ F1.3 (Color)
0.001 Lux @ F1.3 (B/W)
Pan/Tilt/Zoom Functionalities
ePTZ:
48x digital zoom (4x on IE plug-in, 12x built in)
IR Illuminators
30 meters
On-board Storage
Slot type: MicroSD/SDHC/SDXC card slot
Seamless Recording
Video
Compression
H.265 & H.264 & MJPEG
Maximum
Frame RateH.265 & H.264:
30 fps @ 2560x1920
60 fps @ 1920x1080
MJPEG:
12 fps @ 2560x1920
30 fps @ 1920x1080
Maximum Streams
4 simultaneous streams
S/N Ratio
57 dB
Dynamic Range
100 dB
Video Streaming
Adjustable resolution, quality and bitrate
Smart Stream II
Image Settings
Time stamp, text overlay, flip & mirror
Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks
Scheduled profile settings, 3DNR, video rotation, defog, DIS
Audio
Audio Capability
Two-Way Audio (full duplex)
Compression
G711, G726
Interface
Internal microphone input
Audio output
Effective Range
5m
Network
Users
Live viewing for up to 10 clients
Protocols
IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X, UDP, ICMP, ARP, SSL, TLS
Interface
10 Base-T/100 BaseTX Ethernet (RJ-45)
*It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard.
ONVIF
Supported, specifications available at www.onvif.org
Intelligent Video
Video Motion Detection
Five-window video motion detection
VCA*
Line crossing detection, field detection, loitering detection
Alarm and Event
Alarm Triggers
Motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection, audio detection
Alarm Events
Event notification using digital output, HTTP, SMTP, FTP, NAS server and SD Card
File upload via HTTP, SMTP, FTP, NAS server and SD card
General
Smart Focus System
Remote focus
Connectors
RJ-45 cable connector for Network/PoE connection
Audio input
Audio output
DC 12V power input
Digital input*1
Digital output*1
LED Indicator
System power and status indicator
Power Input
DC12V
IEEE 802.3af/at PoE Class 0
Power Consumption
Max. 12.8 W
Dimensions
Ø 138 x 103 mm
Weight
530 g
Safety Certifications
CE, LVD, FCC Class B, VCCI, C-Tick, UL
Operating Temperature
Starting Temperature: 0°C ~ 50°C (32°F ~ 122°F )
Working Temperature: -10°C ~ 50°C (14°F ~ 122°F )
Humidity
90%
Warranty
36 months
System Requirements
Operating System
Microsoft Windows 8/7/Vista/XP/2000
Web Browser
Mozilla Firefox 7~43 (streaming only)
Internet Explorer 7/8/9/10/11
Other Players
VLC: 1.1.11 or above
Quicktime: 7 or above
Included Accessories
CD
User's manual, quick installation guide, Installation Wizard 2, VAST
Others
Quick installation guide, screw pack, alignment sticker
