System Information
|
CPU
|
- Multimedia SoC (System-on-Chip)
|
|
Flash
|
|
|
RAM
|
|
|
|
Camera Features
|
Image sensor
|
|
|
Maximum Resolution
|
|
|
Lens Type
|
- 20x optical zoom, auto focus
|
|
Focal Length
|
|
|
Aperture
|
|
|
Auto-iris
|
|
|
Field of View
|
- 3° ~ 55° (horizontal)
- 2° ~ 32° (vertical)
- 3° ~ 64° (diagonal)
|
|
Shutter Time
|
- 1/1 sec. to 1/10,000 sec.
|
|
WDR Technology
|
|
|
Day & Night
|
- Removable IR-cut filter for day & night function
|
|
Minimum Illumination
|
- 0.02 Lux @ F1.6 ( Color ), 50 IRE (Color)
- 0.001 Lux @ F1.6 ( B/W ), 50 IRE (B/W)
|
|
Pan speed
|
|
|
Pan range
|
|
|
Tilt speed
|
|
|
Tilt range
|
|
|
Preset Locations
|
|
|
Pan / Tilt / Zoom
|
- 48x digital zoom (4x on IE plug-in, 12x built-in)
- Auto pan mode
- Auto patrol mode
|
|
On-board Storage
|
|
|
|
Video
|
Compression
|
|
|
Maximum Frame Rate
|
- H.264: 30 fps @ 1920x1080, 60 fps @ 1280x720
- MPEG-4: 30 fps @ 1920x1080, 60 fps @ 1280x720
- MJPEG: 30 fps @ 1920x1080, 60 fps @ 1280x720
- (Up to 30/15 fps in WDR mode)
|
|
Maximum Streams
|
|
|
S/N Ratio
|
|
|
Dynamic Range
|
|
|
Video Streaming
|
- Adjustable resolution, quality and bit rate
- Zoom enhancement for better image quality under limited bandwidth
|
|
Image Settings
|
- Adjustable image size, quality and bit rate
- Time stamp, text overlay, flip & mirror
- Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks (Up to 24)
- Scheduled profile settings
|
|
|
Audio
|
Audio Capability
|
- Audio input / Audio output (Full duplex)
|
|
Compression
|
|
|
Interface
|
- External microphone input
- External line output
|
|
|
Network
|
Users
|
- Live viewing for up to 10 clients
|
|
Protocols
|
- IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X, ICMP, UDP
|
|
Interface
|
- 10 Base-T / 100BaseTX Ethernet (RJ-45)
|
|
ONVIF
|
- Supported, specification available at www.onvif.org
|
|
|
Intelligent Video
|
Video Motion Detection
|
- Triple-window video motion detection
|
|
Auto-Tracking
|
- Auto-tracking on moving object
|
|
|
Alarm and Event
|
Alarm Triggers
|
- Video motion detection, manual trigger, periodical trigger, system boot, recording notification, audio detection
|
|
Alarm Events
|
- Event notification using digital output, HTTP, SMTP, FTP and NAS server
- File upload via HTTP, SMTP, FTP and NAS server
|
|
|
General
|
Connectors
|
- RJ-45 cable connector for Network/PoE connection
- Audio input
- Audio output
- DC 12V power input
- Digital input*4
- Digital output*2
- RS-485 for PTZ control (PelcoD protocol, Baud rate 2400)
|
|
LED Indicator
|
- System power and status indicator
|
|
Power input
|
- PoE plus (IEEE 802.3at compliant)
- High Power PoE
- AC 24V
|
|
Power consumption
|
- PoE plus:
- AC 24V:
- Max. 48W (heater on)
- Max. 19W (heater off)
- High Power PoE:
- Max. 48W (heater on)
- Max. 19W (heater off)
|
|
Dimensions
|
|
|
Weight
|
|
|
Casing
|
- Weather-proof IP66- and NEMA 4X-rated metal housing
- Built-in electrical dehumidifier device (SD8363E-M)
|
|
Safety Certifications
|
- CE, C-Tick, FCC Class A, NEMA 4X, VCCI
|
|
Operating Temperature
|
- -5°C ~ 55°C (PoE Plus)
- -40°C ~ 55°C (AC 24V / High Power PoE)
|
|
Warranty
|
|
|
|
System Requirements
|
Operating System
|
- Microsoft Windows 7/Vista/XP/2000
|
|
Browser
|
- Mozilla Firefox 7~10 (Streaming only)
- Internet Explorer 7.x or 8.x
|
|
Other Players
|
- VLC: 1.1.11 or above
- QuickTime: 7 or above
|
|
