System Information
| CPU |
- Multimedia SoC (System-on-Chip)
|
| Flash |
|
| RAM |
|
|
Camera Features
| Image sensor |
|
| Maximum Resolution |
|
| Lens Type |
|
| Focal Length |
|
| Aperture |
|
| Auto-iris |
|
| Field of View |
- 34° ~ 80° (horizontal)
- 27° ~ 62° (vertical)
- 44° ~ 101° (diagonal)
|
| Shutter Time |
- 1/5 sec. to 1/10,000 sec.
|
| WDR Technology |
|
| Day & Night |
- Removable IR-cut filter for day & night function
- Smart IR Technology to avoid overexposure
|
| Minimum Illumination |
- 0.07 Lux @ F1.2, 50 IRE ( Color )
- 0.001 Lux @ F1.2, 50 IRE ( B/W )
|
| Pan / Tilt / Zoom |
- ePTZ: 48x digital zoom (4x on IE plug-in,12x built in)
|
| IR Illuminators |
- Built-in IR illuminators, effective up to 30 meters
- IR LED*4, with Smart IR Technology
|
| On-board Storage |
|
|
Video
| Compression |
|
| Maximum Frame Rate |
- In both compression modes:
|
| Maximum Streams |
|
| S/N Ratio |
|
| Dynamic Range |
|
| Video Streaming |
- Adjustable resolution, quality and bitrate
|
| Image Settings |
- Time stamp, text overlay, flip & mirror
- Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks, scheduled profile settings, 3D noise reduction, EIS, video rotation
|
|
Audio
| Audio Capability |
- Two-way audio (full duplex)
|
| Compression |
|
| Interface |
- External microphone input
- Audio output
|
|
Network
| Users |
- Live viewing for up to 10 clients
|
| Protocols |
- IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X, UDP, ICMP
|
| ONVIF |
- Supported, specification available at www.onvif.org
|
| Interface |
- 10Base-T/100 BaseTX Ethernet (RJ-45)
|
|
Intelligent Video
| Video Motion Detection |
- Triple-window video motion detection
|
|
Alarm and Event
| Alarm Triggers |
- Video motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection
|
| Alarm Events |
- Event notification using digital output, HTTP, SMTP, FTP and NAS server
- File upload via HTTP, SMTP, FTP and NAS server
|
|
General
| Smart Focus System |
|
| Connectors |
- RJ-45 for Network/PoE connection
- Audio input/output
- AV output
- AC 24V power input
- DC 12V power input
- Digital input*1
- Digital output*1
|
| LED Indicator |
- System power and status indicator
|
| Power input |
- DC12V/AC24V
- IEEE 802.3af PoE
|
| Power consumption |
- DC Max. 11W
- AC Max. 24.4W
- PoE Max. 11W
|
| Dimensions |
|
| Weight |
- Net: 1,270g (Body only)
- Net: 1,867g (with stand and sunshield)
|
| Casing |
- Weather-proof IP67-rated housing
|
| Safety Certifications |
- CE, LVD, FCC Class A, VCCI, C-Tick, UL
|
| Operating Temperature |
- Starting Temperature: -10°C ~ 50°C (14°F ~ 122°F)
- Working Temperature: -20°C ~ 50°C (-4°F ~ 122°F)
|
| Warranty |
|
|
System Requirements
| Operating System |
- Microsoft Windows 8/7/Vista/XP/2000
|
| Browser |
- Mozilla Firefox 7~10 (Streaming only)
- Internet Explorer 7/8/9/10
|
| Other Players |
- VLC: 1.1.11 or above
- QuickTime: 7 or above
|
|
