KNS Shop 購物價惠：
** 部份地區免費送貨
** 電話技術支援安裝
** 保證原庄跟機配件
** 提供七天售後保障 (只限非人為損壞)
KNS承諾所有網路攝影機均屬全新香港行貨 ㊣
並享有原廠保用服務 (條款以代理商提供為準)
*所有地區加$380包基本安裝服務, 第2支起加$300
請即致電 3170 7019 或電郵至 info@knshk.com 查詢及訂購。
Camera
Image Sensor:
1/4" SONY Super HAD CCD
Effective Pixels:
PAL:752(H)x582(V); NTSC:768(H)x494(V)
Horizontal Resolution:
480TVL
Signal System:
PAL/NTSC
Minimum Illumination:
1.0Lux / F1.4
White Balance:
ATW / Manual
AGC:
Auto/Manual
S/N Ratio:
Better than 50dB
BLC:
ON/OFF
Electronic Shutter:
N: 1/60~1/10
Day& Night:
Electronic
Digital Zoom:
Up to 12x
Privacy Masking:
Up to 24 zones, and support up to 8 zones masked simultaneously in 1 image
Auto Focus:
Auto/Manual
Lens
Focal Length:
4.1~73.8mm,18X
Zoom Speed:
Approx. 2.1sec (Optical WIDE-TELE )
Angle of View:
48° to 2.8°(WIDE-TELE )
Minimum Working Distance:
290mm (WIDE)
Aperture Range:
F1.4-F3.0
Pan & Tilt
Pan Range:
360° continuous
Pan Speed:
Manual: approx. 0.3°/s-160°/s or 0.3°/s-220°/s
Tilt Range:
0°~90° , support auto flip
Tilt Speed:
Manual: approx. 0.5°/s-40°/s or 0.5°/s-60°/s
Proportional Zoom:
Support
Number of Preset:
200
Patrol:
8
Pattern:
4
Power-off Memory:
Support
Park Action:
Call Preset/Patrol/Pattern/Auto Scan/Random Scan/Frame Scan after a pre-defined inactivity time interval
PTZ Position Display:
ON/OFF
Alarm
Alarm Input:
2 channel signal input with adjustable priority
Alarm Output:
2 channel relay output, with configurable alarm actions
Alarm Actions:
Preset 1 ~ 200, Patrol 1 ~ 8, Pattern 1 ~ 4, SD card recording, Terminal output, Notification on Client
Input & Output
Monitor Output:
1.0Vp-p, 75 Ohm, BNC
Audio Input:
1 channel Mic. Input (applicable microphone, plug-in power type), 2.0~2.4Vp-p, 1k Ohm±10%
Audio Output:
1 channel audio output, linear level
Network
Ethernet:
10Base -T, /100Base-TX, RJ45 Connector
Max.Image Resolution:
PAL:704x576; NTSC: 704x480
Frame Rate:
25fps (704×576)
Image Compression:
H.264
Audio Compression:
OggVorbis, 16Kbps
Audio Mode:
OFF/Audio input/Audio output
Protocols:
TCP/IP
No. of Simultaneous Users:
Up to 6 user connections at the same time
Dual Stream:
Support
Mini SD Card:
Manual record/Alarm record. Compatible with SDHC standard cards.
Security Measures:
User authentication (ID and password), Host authentication (MAC)
Client GUI
Camera Control:
Pan/Tilt, Zoom, Focus, Click centering, Zoom by mouse dragging, Iris, preset calling and programming, auto mode
Clock Display:
Time: Week: Date, 6 formats on the Client
General
Menu Language:
English / Chinese
RS-485 Protocols:
Hikvision, Pelco-P, or Pelco-D protocols (protocol types can be extended)
Power Supply:
24V AC (12V DC optional)
Power Consumption:
30W Max (Heater ON)
Working Temperature/Humidity:
-30°C ~ 60°C
Protection Level:
IP66 with TVS 3000V lightning protection, surge protection and voltage transient protection
Dimensions:
6 inch
Weight (approx.):
5kg
備註：
1. 上門設定是包括有：網絡攝像機(IP Camera)和寬頻分享器之接駁 (包 6 呎以下電腦 CAT5 線) 連 IP 及 Port 位設定，免費動態網址(DDNS)之申請，測試網絡攝像機於內聯網 ( Intarnet ) 及互聯網 ( Internet ) 之運作是否正常，一部指定類別手提裝置監控設定協助。無線寬頻分享器之上網連接及無線設定連測試 (如一併購買)。
2. 上述之售價並不包括：錄影軟件之安裝，電腦維修及檢查，放線(釘線), 上鏍絲, 鑽牆, 掛機等工程項目；如果有需要掛機，請事前通知及先行報價後才可安排服務。
3. 上門基本安裝服務之地區：除了離島、機場或下車後步行時間多於15分鐘之路程外 (需另加HK$100-HK$200附加收費)；其他地區也可以，詳情請致電 3170 7019查詢。
4. 上門設定服務時間為：星期一至星期五，上午10:00至下午7:00，星期六至下午4:00，星期日及公眾假期休息。
5. 上門服務為一次過性質之服務，如有需要再次上門，收費為HK$350 (離島、機場或下車後步行時間多於15分鐘之路程除外)。
