KNS Shop 購物價惠：
** 部份地區免費送貨
** 電話技術支援安裝
** 保證原庄跟機配件
** 提供七天售後保障 (只限非人為損壞)
KNS承諾所有DVR均屬全新香港行貨 ㊣
並享有原廠保用服務 (條款以代理商提供為準)
請即致電 3170 7019 或電郵至 info@knshk.com 查詢及訂購。
| Video/Audio Input |
| Video Compression: |
H.264 |
| Analog Video Input: |
16-ch, BNC(1.0Vp-p, 75Ω), PAL/NTSC adaptive |
| IP Video Input: |
16-ch 4CIF/8-ch 720P Real Time, or 8-ch UXGA not Real Time |
| Composited Video Input: |
up to 24-ch (Analog video + IP video) |
| Audio Compression: |
OggVorbis |
| Audio Input: |
16-ch, BNC(2.0Vp-p, 1kΩ) |
| Voice Talk Input: |
2-ch, BNC(2.0Vp-p, 1kΩ) |
|
| Video/Audio Output |
| Preview Resolution: |
PAL:704×576 NTSC:704×480 |
| CVBS Output: |
2-ch, BNC(1.0Vp-p, 75Ω) |
| VGA Output: |
1, resolution: 1024×768/60Hz, 1024×768/70Hz, 1280×1024/60Hz |
| Recording Resolution: |
UXGA/720P/4CIF/DCIF/2CIF/CIF/QCIF |
| Frame Rate: |
PAL: 25fps, NTSC: 30fps |
| Video Bit Rate: |
32Kbps~2048Kbps, or user-defined (Max. 6144Kbps) |
| Audio Output: |
2-ch, BNC(linear electrical level, 600Ω) |
| Audio Bit Rate: |
16kbps |
| Synchronous Playback: |
16-ch |
| Dual Streams: |
Yes |
|
| Hard Disk Driver |
| Interface Type: |
8 SATA interface |
| Capacity: |
Each interface supports up to 2TB capacity |
|
| External Interface |
| Network Interface: |
1, RJ45 10M/100M/1000M adaptive Ethernet interface |
| Serial Interface: |
1 RS-232 interface (for parameters configuration, maintenance , transparent channel);
1 RS-485 interface (for PTZ control);
1 RS-485 keyboard interface (for special keyboard control) |
| USB Interface: |
3, USB2.0 |
| Alarm Input: |
16-ch |
| Alarm Output: |
4-ch |
|
| General |
| Power Supply: |
100~240VAC, 6.3A, 50~60Hz |
| Consumption: |
≤70W (without hard disk or DVD-R/W) |
| Working Temperature: |
-10°C~+55°C(14°F~131°F) |
| Working Humidity: |
10%~90% |
| Chassis: |
19" standard 2U chassis |
| Dimension: |
450(D)×450(W)×95mm(H)(17.72"(D)×17.72"(W)×3.74"(H)) |
| Weight(Without HDD): |
≤8000g(17.64lbs) |
|
