Video/Audio Input
Video Compression:
H.264
PAL/NTSC Adaptive:
Support
Video Input:
8-ch
Video Input Interface:
BNC (1.0Vp-p, 75Ω)
Audio Compression:
OggVorbis
Audio Input:
4-ch
Audio Input Interface:
RCA (2Vp-p, 1kΩ)
Voice Talk Input:
1-ch (1st channel of Audio In)
Video/Audio Output
Preview Resolution:
PAL: 704x576; NTSC: 704x480
VGA Output:
1-ch, resolution: 1024×768/60Hz
Recording resolution:
4CIF/2CIF/CIF/QCIF
Video output:
2-ch, BNC(1.0Vp-p, 75Ω)
Video Loop Output:
8-ch, DB15
Frame Rate:
Model1:
4CIF: 8fps;2CIF: 16fps;
CIF: 25(P)/30(N)fps
Model2:
channel 1: 4CIF: 25(P)/30(N)fps
others: CIF: 25(P)/30(N)fps
Video Bit Rate:
32Kbps~1024Kbps, or user-defined
Audio Output:
1-ch RCA(Linear electrical level, 600Ω)
Audio Bit Rate:
16kbps
Synchronize Playback:
8-ch
Hard Disk Driver
Interface Type:
4 SATA Interfaces
Capacity:
Each interface supports up to 2TB capacity
External Interface
Network Interface:
1 RJ45 10M/100M adaptive Ethernet Interface
USB Interface:
2 USB2.0 Interface
Serial Interface:
1 RJ45 RS-232 interface; 1 RS-485 interface (for PTZ control); 1 RS-485 keyboard interface (for keyboard control)
Alarm Input:
16-ch
Alarm Output:
4-ch
General
Power Supply:
100~240VAC, 6.3A, 50~60Hz
Consumption:
≤40W(without hard disk or DVD-R/W)
Working Temperature:
-10°C ~+ 55°C(14°F~131°F)
Working Humidity:
10%~90%
Chassis:
19” standard chassis
Dimension:
70mm(H)×440mm(W)×390mm(D)
Weight:
≤8Kg(without hard disk or DVD-R/W)
