Output Power Capacity
1980 Watts / 2200 VA
Max Configurable Power
1980 Watts / 2200 VA
Nominal Output Voltage
230V
Output Voltage Distortion
Less than 5%
Output Frequency (sync to mains)
50/60Hz +/- 3 Hz
Other Output Voltages
208, 220, 240
Topology
Line Interactive
Output Connections
| (8) IEC 320 C13 |
 |
| (1) IEC 320 C19 |
 |
| (2) IEC Jumpers |
|
Nominal Input Voltage
208V, 230V
Input Frequency
50/60 Hz +/- 3 Hz (auto sensing)
Input Connections
| IEC-320 C20 |
|
| Schuko CEE 7 / EU1-16P |
|
| British BS1363A |
|
Input voltage range for main operations
140 - 280V
Other Input Voltages
220, 240
Battery Type
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Typical recharge time
3 hour(s)
| Curve |
Part Number(s) |
| A |
SMX2200RMHV2U |
| B |
SMX2200RMHV2U
+ (1)SMX120RMBP2U |
| C |
SMX2200RMHV2U
+ (2)SMX120RMBP2U |
| D |
SMX2200RMHV2U
+ (3)SMX120RMBP2U |
| E |
SMX2200RMHV2U
+ (4)SMX120RMBP2U |
| Load |
Efficiency |
| 25% |
93.2% |
| 50% |
96.4% |
| 75% |
97.5% |
| 100% |
98.1% |
Communications & Management
Interface Port(s)
SmartSlot, USB
Available SmartSlot™ Interface Quantity
1
Control panel
LED status display with On Line : On Battery : Replace Battery and Overload indicators, Multi-function LCD status and control console
Audible Alarm
Alarm when on battery : distinctive low battery alarm : configurable delays
Emergency Power Off (EPO)
Yes
Surge Protection and Filtering
Surge energy rating
645 Joules
Filtering
Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Shipping Height
243.00 mm
Pallet Dimensions
39.37 inches
# of Units per Layer per Pallet
2
Operating Environment
0 - 40 °C
Operating Relative Humidity
0 - 95%
Operating Elevation
0-3000 meters
Storage Temperature
-15 - 45 °C
Storage Relative Humidity
0 - 95%
Storage Elevation
0-15000 meters
Audible noise at 1 meter from surface of unit
55.00 dBA
Online Thermal Dissipation
150.00 BTU/hr
Regulatory Approvals
C-tick, CE, CSA, EN 50091-1, EN 50091-2, FCC Part 15 Class A, GOST, IEC 60950, IRAM, UL 1778, VDE
Standard Warranty
3 years repair or replace (excluding battery) and 2 year for battery, optional on-site warranties available, optional extended warranties available
![APC Smart-UPS X 2200VA Rack/Tower LCD 200-240V [P/N: SMX2200RMHV2U]](https://www.knshk.com/image/cache/data/product/SMX3000RMHV2U-500x500.jpg "APC Smart-UPS X 2200VA Rack/Tower LCD 200-240V [P/N: SMX2200RMHV2U]")
