- Product Segment
AC3100 ultimate AC performance : 1000+2167 Mbps
- Coverage
Very large homes
- Data Rate
802.11a : 6,9,12,18,24,36,48,54 Mbps
802.11b : 1, 2, 5.5, 11 Mbps
802.11g : 6,9,12,18,24,36,48,54 Mbps
802.11n : up to 600 Mbps
802.11ac : up to 1734 Mbps
1024QAM (2.4GHz) : up to 1000 Mbps
1024QAM (5GHz) : up to2167 Mbps
- Antenna
External antenna x 4
- Transmit/Receive
MIMO technology
2.4 GHz 4 x 4
5 GHz 4 x 4
- Processor
1.4 GHz dual-core processor
- Memory
128 MB Flash
512 MB RAM
- Wi-Fi Technology
Beamforming: standard-based and universal
1024-QAM high data rate
20/40/80 MHz bandwidth
- Operating Frequency
2.4 GHz / 5 GHz
- Encryption
64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK, WPA-Enterprise , WPA2-Enterprise , WPS support
- Firewall & Access Control
Access control：Parental control, Network service filter, URL filter, Port filter
- Management
UPnP, IGMP v1/v2/v3, DNS Proxy, DHCP, SNMP, NTP Client, DDNS, Port Trigger, Virtual Server, DMZ, System Event Log
- WAN Connection Type
Internet connection type : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP
- Utilities
Router setup wizard; Firmware restoration; Device discovary; printer setup utility
- Ports
RJ45 for Gigabits BaseT for WAN x 1, RJ45 for Gigabits BaseT for LAN x 8
USB 2.0 x 1
USB 3.0 x 1
- Button
WPS Button, Reset Button, Power Button, Wireless on/off Button, LED on/off Button
- Features
Link Aggregation
MU-MIMO
Traffic Analyzer
Adaptive QoS
AiProtection
Parental Control
Guest Network : 2.4 GHz x 3, 5 GHz x 3
VPN server : IPSec Pass-Through, PPTP Pass-Through, L2TP Pass-Through, PPTP Server, OpenVPN Server
VPN client : PPTP client, L2TP client, OpenVPN client
Mac OS Backup
Enhanced media server (AiPlayer app compatible)
- Image : Jpeg
- Audio : mp3, wma, wav, pcm, mp4, lpcm, ogg
- Video : asf, avi, divx, mpeg, mpg, ts, vob, wmv, mkv, mov
AiCloud personal cloud service
3G/4G data sharing
Printer Server
- Multifunctional printer support (Windows only)
- LPR protocol support
Download Master
- Support bt, nzb, http, ed2k
- Support encryption, DHT, PEX and magnet link
- Upload and download bandwidth control
- Download scheduling
AiDisk file server
- Samba and FTP server with account management
Dual WAN
IPTV support
Roaming Assist
- LED Indicator
Power x 1
Wi-Fi x 2
WAN x 1
USB x 2
WPS x 1
LAN x 1
- Power Supply
AC Input : 110V~240V(50~60Hz)
DC Output : 19 V with max. 2.37 A current
- Dimensions
11.8 x 7.4 x 3.3 ~ inch (WxDxH)
- Weight
- Operation mode
Wireless router mode
Access point mode
Media bridge mode
