EnGenius ESR Cloud Router [P/N: ESR900]

Technical Specifications

Device Interface
Gigabit WAN Port
4 Gigabit LAN Ports
USB2.0 Port
Push Button for WPS
Reset Button

IEEE Standards
802.11a/b/g/n
Up to 450 Mbps wireless speed in both the 2.4 and 5 GHz frequency bands

802.3i/u/ab

LED Indicators
Power
WLAN (Wireless Connection)
Internet

Package Contents
ESR900 Router
Power Adapter (12V 1.5A)
Quick Start Guide
RJ45 Ethernet Cable

Power Specification
External Power Adapter
DC In, 12V 1.5A

Certifications
FCC/CE/IC

Physical/Environmental Conditions
Operating Temperature: 0º~40º
Humidity: 90% or less (non-condensing)
Storage Temperature: -20º~60º
Humidity: 95% or less (non-condensing)

Maximum data rates are based on IEEE 802.11 standards. Actual throughput and range may vary depending on many factors including environmental conditions, distance between devices, radio interference in the operating environment, and mix of devices in the network. EnGenius Technologies, Inc. EnShare™ supports both FAT32 and NTFS USB formats. Transfer speeds of data from your router-attached USB storage device to a remote/mobile device may vary based on Internet uplink and downlink speeds, bandwidth traffic at either send or receive locations, the data retrieval performance of the attached storage device or other factors. EnGenius does not guarantee compatibility with all USB drives. EnGenius does not guarantee compatibility for media streaming with Smart TVs or other home entertainment devices. EnGenius does not warrant its products or EnShare from loss of data or loss of productivity time. Features and specifications subject to change without notice. Screen images simulated. Apple, the Apple logo, iPad and iPhone are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service mark of Apple Inc.  Android and Google Play are trademarks of Google Inc.  Trademarks and registered trademarks are the property of their respective owners. For United States of America: Copyright ©2013 EnGenius Technologies, Inc. All rights reserved.

Software Features

Frequency Bands
2.400~2.484 GHz (11b/11g/11n)

5.18~5.82 GHz (11a/11n)

Operating Mode
AP Router/WDS

Wireless Features
Auto Channel Selection
Output Power Control
WMM (Wireless Multimedia)
MSSID (Multiple SSID)

Security

WEP/WPA-PSK/WPA2-PSK
TKIP/AES
Hidden SSID
MAC Address Filtering
802.1X Authentication
DDoS
DHCP Server/Client
SPI (Static Packet Inspection)
NAT
Port Forwarding
DMZ
Port Mapping/Triggering

VPN with PPTP, L2TP, IPSec, L2TP over IPSec

VPN Tunnels: 5

QoS

IP Filtering
Port Filtering
DDNS
IPv6 Pass-through
MAC Clone
Traffic Monitor
WAN Type: PPPoE/DHCP/Static IP
USB Features: SAMBA

Dimensions and Weights

ESR900 Device
Weight: 0.5 lbs.
Diameter: 6.36”
Height: 1.64”

Warranty

1 Year
