Technical Specifications QoS
Standard
IEEE 802.11b/g/n on 2.4 GHz
IEEE 802.11a/n/ac on 5 GHz
IEEE 802.3at
Antenna
5 dBi Internal Omni-Directional Antennas
Physical Interface
2 x 10/100/1000 Gigabit Ethernet Ports
- LAN1: Supports 802.3at PoE Input
- LAN2: Data Pass Through
1 x Reset Button
1 x Power Connector
Physical Security
Kensington Security Slot
LED Indicators
1 x Power
1 x WLAN (Wireless Connection)
1 x LAN
Power Source
External Power Adapter on PoE injector
DC IN, 48 V/0.8A
IEEE 802.3at Compliant Source
Active Ethernet (PoE)
Mounting
Wall Mount
Pole Mount
Memory Capacity
Memory: 128 MB
Flash Memory 16 MB
Wireless & Radio Specifications
Dual Band
Operation Modes
Access Point
Peak Power
Up to 23W
Transmit Power
Up to 27 dBi on 2.4 GHz
Up to 26 dBi on 5 GHz
Max transmit power is limited by regulatory power
Radio Chains/Spatial Streams
2x2:2
Supported Data Rates (Mbps)
2.4 GHz: Max 300
5 GHz: Max 867
802.11b: 1, 2, 5.5, 11
802.11g: 6, 9, 12, 18, 24, 36, 48, 54
802.11n: 6.5 to 300 (MCS0 to MCS15)
802.11ac: 6.5 to 867 (MCS0 to MCS9, NSS=1~3)
Supported Radio Technology
802.11b: Direct-Sequence Spread-Spectrum (DSSS)
802.11a/g/n/ac: Orthogonal frequency-division Multiplexing (OFDM)
Channelization
802.11ac with 20/40/80 MHz channel width
802.11n with 20/40 MHz channel width
802.11a/b/g with 20 MHz channel width
Supported Modulation
802.11b: BPSK, QPSK, CCK
802.a/g/n: BPSK, QPSK, 16-QAM, 64-QAM
802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM
Management
Multiple BSSID
Supports up to 16 SSIDs, 8 SSIDs per radio
VLAN Tagging
Supports 802.1q SSID-to-VLAN tagging
VLAN Pass through
Spanning Tree
Compliant with IEEE 802.11e Standard
WMM
SNMP
v1, v2c, v3
MIB
I/II, Private MIB
Management Features
Deployment Options
Standalone (Individually Managed)
Managed Mode (with Neutron Series Switch/ezMaster)
Auto-Channel Selection
Wireless STA (Client) Connection List
Guest Network
Mobility: PMKSA Support for Fast Roaming
Backup/Restore Settings
Auto Reboot
Client Statistics
E-Mail Alert
Configuration
Web Interface (HTTP)
CLI (Telnet)
Control Features
Managed Mode (by Neutron Switch/ezMaster)
CLI Supported
Band Steering
Auto Reboot
One-Click Firmware Upgrade
Firmware Upgrade: Web interface or CLI (FTP/HTTP)
Security
WEP Encryption (64/128/152 bit)
WPA/WPA2 Enterprise (PSK using TKIP or AES)
Hide SSID in beacons
MAC Address Filtering, up to 50 MACS per SSID
Https Support
SSH Support
Client Isolation
Environment & Mechanical
Temperature Range
Operating: -4°F to 140°F, -20°C to 60°C
Storage: -22°F to 176°F, -30°C to 80 °C
Humidity (Non-condensing)
Operating: (90% or less
Storage: 90% or less
Ingress Protection Marking
IP55-Rated Enclosure
Certifications
FCC, IC
Device, Packaging & Master Carton Dimensions & Weights
EWS660AP Device
Weight: 1.89 lbs.
Width: 7.13" (181 mm)
Length: 11.97" (304 mm)
Height: 1.81" (46 mm)
Packaging
Weight: 3.43 lbs. (1.55 kg)
Width: 15.87" (403 mm)
Length: 21.18" (538 mm)
Height: 14.61" (371 mm)
Master Carton
Weight: 36.46 lbs. (16.54 kg)
Width: 7.48" (190 mm)
Length: 12.99" (330 mm)
Height: 4.06" (103 mm)
No. of boxes per carton: 10
Package Contents
EWS650AP 11ac Outdoor AP
48 V/0.8A Power Adapter
PoE Injector
Pole Mount Ring
Mounting Screw Set
Quick Installation Guide
