DISPLAY
Type
0.63" (x3) Poly-Si TFT
Resolution
XGA 1024x768 (native); UXGA 1600x1200 (compressed)
Lens
1.2x Manual Optical Zoom / manual focus
Keystone
Vertical Digital keystone correction +/-30 degrees
Display size
40"–300" / 1.0m–7.6m
Throw Distance
3.6 ft. – 28.5 ft. / 1.1m – 8.7m
Throw Ratio
1.43 – 1.72:1
Lamp type
215 watt
Lamp life (normal/eco-mode)
4000 / 6000† hours
Brightness
3000 ANSI Lumens
Contrast Ratio
2000:1 (typ) / 4200:1 (with Active IRIS)
Aspect Ratio
4:3 (native)
Color Gamut
114% NTSC 1931 CIE
Color Depth
24 bits, 16.7M Colors (8+8+8)
COMPATIBILITY
PC
Analog: VGA to UXGA
Mac®
Analog: Up to 1152x870
AUDIO
Speakers
10W (x1)
INPUT SIGNAL
Computer and Video
NTSC M (3.58MHz), 4.43MHz, PAL (B, D, G, H, I, M, N), SECAM, SD (480i/576i), ED (480p/576p), HD (720p/1080i)
Frequency
Fh: 15–100KHz, Fv: 50–100Hz
CONNECTOR
Audio Input
3.5mm mini jack, RCA (L/R)
Audio Out
3.5mm mini jack
Network
RJ-45
RGB Input
15-pin mini D-sub (X2)
Composite Input
RCA jack
S-Video Input
Shared with RGB 1
Component
Shared with RGB 1
RGB Output
Shared with RGB 2
Control
RS-232 (DB-9)
POWER
Voltage
100~240VAC (Auto Switching), 50/60Hz (universal)
Consumption
286W (typ) / <1W (stand-by mode)
CONTROLS
Basic
ON/Stand-By, Auto Setup, Arrow Key Up, Arrow Key Down, Arrow Key Left/Volume Down, Arrow Key Right/Volume Up, Menu, Select
OSD
Input Menu: Computer 1, Computer 2, Video PC Adjust Menu: Auto PC adj, Fine sync, Total dots, Horizontal, Vertical, Current mode, Clamp, Display area H, Display area V, Reset, Mode free, Store Image Select (PC): Dynamic, Standard, Real, Blackboard (Green), Colorboard, Image1~4 Image Select (AV): Dynamic, Standard, Cinema, Blackboard (Green), Colorboard, Image1~4 Image Adjust: Contrast, Brightness, Color*, Tint*, Color Temp, Red, Green, Blue, Sharpness, Gamma, Noise reduction*, Progressive*, Reset, Store (*Only available in video signal) Screen: Normal, True*, Wide, Full*, Custom, Custom adj, Digital Zoom +/-* (*Not available in video signal) Sound: Volume, Mute Setting: Language, Menu position, Auto setup (Input search, Auto PC adj, Auto keystone), Keystone, Background, Display, Logo (Logo select, Capture, Logo PIN code lock, Logo PIN code change), Ceiling, Rear, Terminal (Computer 2, Monitor out), Power management, Direct on, Standby mode (ECO, Network), P-timer, Closed Caption, Lamp control, Remote Control, Security (Key lock, PIN code lock, PIN code change), Fan, Fan control, Video delay control, Lamp counter, Filter counter, Warning log, Factory default Network: LAN mode select, Network setting, Network PIN code, Network information, Network factory default
OPERATING CONDITIONS
Temperature
41ºF–95ºF (5ºC–35ºC)
Humidity
20%–80% (non-condensing)
Altitude
0 to 6,000 ft (1,800m), operational up to 10,000 ft (3048m) at reduced reliability and performance
NOISE LEVEL
Normal
34dB
Eco-mode
29dB
DIMENSIONS (WxHxD)
Physical
13.4 × 4.6 × 9.9 (in) / 341 × 117 × 251 (mm)
Packaging
16.5 × 8.3 × 15.7 (in) / 418 × 210 × 398 (mm)
WEIGHT
Net
6.4 lb. (2.9 kg)
Gross
11.1 lb. (5.0 kg)
REGULATIONS
UL/cUL, FCC B, C-Tick, CCC, CE, WEEE, RoHS, ErP
PACKAGE CONTENTS
Projector, power cable, RGB cable, remote control with batteries, lens cap, Quick Start Guide, ViewSonic Wizard CD (with User Guide)
開箱不良包換期限: 購機14天包換
產品保養期:
2年自攜保養; 包括零件及人工費.
(燈泡屬於耗材部份，僅提供一年保養, 且使用時間700小時內。)
由2011年12月起購買之投影機可享以下升級保養服務:
3年免費上門收送，保養; 包零件及人工費。
(燈泡屬於耗材部份，僅提供一年保養,且使用時間700小時內。)
Both HK & Macau provide on-site service for projector.
*on-site service is meaning pick up & delivery, not on-site repair.
