DISPLAY
Type
0.7" Digital Micromirror Device (DLP™)
Resolution
1920x1080 (1080p)
Lens
1.5× Manual optical zoom / Manual optical focus
Keystone
Vertical digital keystone correction: +/– 20 degrees
Display size
30"–300" / 0.76m–7.6m
Throw Distance
0.9m–10m / 3ft–32.8ft
Throw Ratio
1.4 – 2.14:1
Lamp type
280 watt
Lamp life (normal/eco-mode)
4000 / 5000* hours
Brightness
4000 ANSI Lumens
Contrast Ratio
2600:1 (typ), 3000:1 (dynamic)
Aspect Ratio
16:9 (native) and 4:3
Color Gamut
70% NTSC 1931 CIE
INPUT SIGNAL
Computer and Video
NTSC M (3.58 MHz), 4.43MHz, PAL (B, D, G, H, I, M, N, 60), SECAM (B, D, G, K, K1, L), SD 480i and 576i (24fps, 25fps and 30fps), ED 480p and 576p (24fps, 25fps and 30fps), HD 720p, 1080i and 1080p (24fps, 25pfs and 30fps)
Frequency
Fh: 31–91KHz, Fv: 48–85Hz
COMPATIBILITY
PC
VGA to 1080p
Mac®
Up to 1080p
CONNECTOR
Digital
HDMI 1.3 (x2)
Network
RJ-45
Composite Input
RCA jack
S-Video Input
4-pin mini-DIN
Component
RCA (x3)
Control
RS-232 (DB-9)
RGB (input/output)
15-pin mini D-sub (x2) / 15-pin mini D-sub
Audio (input/output)
3.5mm mini jack / 3.5mm mini jack
USB
Mini-B for direct presentation from computer Type A supports JPEG, BMP, TIFF, PNG, GIF from USB flash drive
Screen Trigger
0.35 plug (12V/1A)
AUDIO
Speakers
10W (x2)
POWER
Voltage
100~240VAC (Auto Switching), 50/60Hz (universal)
Consumption
360W (max) / <1W (stand-by mode)
CONTROLS
Basic
Power, keystone/arrow keys, left/blank, menu/exit, right/panel key lock, auto, mode/enter, source
OSD
Picture: Brightness, Contrast, Color Setting, Keystone, Aspect Ratio, Image, White Intensity, Gamma Computer Image: Frequency, Tracking, H Position, V Position Video Image: Saturation, Sharpnes, Tint Setting: Menu Position, Projection, Signal Type, Lamp Hour, Lamp Hour Reset, Filter Mode, Filter Hours, Filter Hours Reset, Power Saving, Auto Source, Eco-mode, High Altitude, OSD Timeout Advance: Blank Screen, Password Word, Screen Capture, Start up Screen, Digital Zoom, DCR, Close Captions
OPERATING CONDITIONS
Temperature
32ºF–104ºF (0ºC–40ºC)
Humidity
10%–90% (non-condensing)
Altitude
0~6,000 ft (1,800m), operational up to 10,000 ft (3048m)
NOISE LEVEL
Normal
33dB
Eco-mode
29dB
DIMENSIONS (WxHxD)
Physical
13.1 × 4.8 × 10.4 (in) / 332.7× 121.9 × 264.2 (mm)
Packaging
16.3 × 7.5 × 14.8 (in) / 414 ×190.5 × 375.9 (mm)
WEIGHT
Net
8.5 lb (3.86 kg)
Gross
11.8 lb (5.36 kg)
REGULATIONS
CB, RoHS, SVHC, WEEE, UL/cUL, FCC-B, ICES-004, TUV-S (Argentina), NOM, PSB, C-tick, KC, CE, GOST-R, Hygienic, UKrSEPRO, CCC
PACKAGE CONTENTS
ViewSonic projector, power cable, VGA cable, HDMI cable, remote control/laser with batteries, lens cap, Quick Start Guide, ViewSonic Wizard DVD (with User Guide), soft carrying case.
開箱不良包換期限: 購機14天包換
產品保養期:
2年自攜保養; 包括零件及人工費.
(燈泡屬於耗材部份，僅提供一年保養, 且使用時間700小時內。)
由2011年12月起購買之投影機可享以下升級保養服務:
3年免費上門收送，保養; 包零件及人工費。
(燈泡屬於耗材部份，僅提供一年保養,且使用時間700小時內。)
Both HK & Macau provide on-site service for projector.
*on-site service is meaning pick up & delivery, not on-site repair.
