Common Specifications
Dimensions99.5 x 97.8 x 33.05 mm (3.92 x 3.85 x 1.30")
Weight215 g (7.58 oz)
Max. TX Power22 dBm
MIMO2.4 GHz: 2x2, 5 GHz: 2x2
Speeds2.4 GHz: 300 Mbps, 5 GHz: 867 Mbps
Networking InterfaceWi-Fi/Gigabit Ethernet (1) WAN, (1) LAN
Maximum Power Consumption9W
ButtonsReset
Antennas(1) Dual-Band Antenna
Display30.73 mm (1.21") diagonal, 160 x 64, 142 ppi, Capacitive Touch, Grayscale
Wi-Fi Standards802.11ac
Power SaveSupported
Wireless SecurityWPA2-PSK AES/TKIP
Operating Temperature14 to 131° F (-10 to 55° C)
Operating Humidity5 to 95% Noncondensing
CertificationsFCC / CE / IC
Supported Data Rates
802.11ac13 Mbps to 1300 Mbps (MCS0 - MCS9, VHT 20/40/80)
802.11n6.5 Mbps to 450 Mbps (MCS0 - MCS23, HT 20/40)
802.11a6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b1, 2, 5.5, 11 Mbps
802.11g6, 9, 12, 18, 24, 36, 48, 54 Mbps
